Coefficient RR - Road Race Carbon Handlebar - Top Down View
Coefficient RR - Road Race Carbon Handlebar - Frontal View
Coefficient RR - Road Race Carbon Handlebar - Frontal Side View
Coefficient RR (Road Race) Carbon Handlebar
Uri riding his Coefficient RR Road Race Bars
Evan Pardi testing the Coefficient RR bars
$399.00

Coefficient RR
(Road Race)
Carbon Handlebar

The Coefficient RR handlebar is purpose-built for riders that race frequently on pavement and/or gravel.​

Free Garmin and Wahoo GPS Mount with every RR: If you require an alternative GPS Mount for your Coefficient RR, please add to your basket.



+

Ideally Suited For:

The RR's patent pending integrated computer bridge is not just a perch for your favourite data capturing gizmo, it offers hand placement options to powerfully and comfortably lift you over a steep climb AND/OR stretch-out and narrow-up to bridge a gap or breakaway from the pack. Designed within UCI and ITU rules, the Wave RR will change your cycling experience for the better.

Both the AR and RR feature Coefficient aero-ergonomics that make it easier to ride faster on the noon ride or an all-day ride. With a deeper drop and increased rigidity, the RR promotes a more aggressive, aerodynamic riding position. Our patented Coefficient SWOPE (sloping, sweeping bar tops) carries over from the AR to relax your upper body and improve respiratory and neuromuscular function.

The RR Bar is Shimano Di2 compatible. It not only accepts the bar end junction, it includes exit holes for remote shifter buttons in four locations (2 each side) on the underside of the tops.

Computer Compatibility

In partnership with Bar Fly Bike, the Coefficient RR includes your choice of the following cycling computer mounts: Garmin, Wahoo, Lezyne, Polar, Cateye, Bryton, Joule, Hammerhead, Magellan and Mio. We also offer a GoPro camera mount that attaches to the underside of the computer bridge. Replacement mounts can be ordered as well.


Lightweight Materials & Dependability

When comparing handlebar weights keep in mind that the average off-the-front computer mount weighs in at 30 to 40 grams. The Coefficient RR is moulded using Toray unidirectional carbon fibre and tested to the highest ISO international standards for professional road and mountain bike racing.


First Impressions


Proportional Sizing & Specifications

Available Sizes (C to C) 38cm 40cm 42cm 44cm
Clamp Diameter 31.8mm
Drop 127mm
Reach 77mm
SWOPE (sweep + slope) Sweep: 12 degrees  /  Slope 15 degrees
Flare 7 degrees
Drop Width (C to C) 40cm 42cm 44cm 46cm
Stem to Computer (C to C) 87mm
Clamp Area Width 56mm
Aero Top Width 43mm 45mm 47mm 49mm
Weight (grams) 310 315 320 325


Installation Instructions


DOWNLOAD RR INSTALLATION PDF


* Please Note: GPS Unit shown in photography is not included with the Coefficient RR.
